Description
| CAMERA SPECIFICATION | |
| Min. Illumination | 0.02 lux @F1.6, AGC ON; 0 lux with illumination on |
| DISPLAY SPECIFICATION | |
| Lens Mount | M12 |
| Lens | 2.8mm@F1.6, Horizontal FoV: 106°; Vertical FoV:57°; Diagonal FoV:124° 3.6mm@F1.6, Horizontal FoV:90°; Vertical FoV:47°; Diagonal FoV:107° |
| SUMMARY | |
| Storage Conditions | -30°C ~ 65°C (-22°F~149°F), Humidity: less than 95% (non-condensing) |
| Operating Conditions | 30°C ~ 60°C (-22°F~140°F), Humidity: less than 95% (non-condensing) |
| HARDWARE FEATURES | |
| Electronic Shutter | 1 / 3s ~ 1 / 100000s |
| Image Size | 3840×2160 |
| Power Consumption | < 7W |
| TECHNICAL SPECIFICATION | |
| Ingress Protection | IP67 |
| GENERAL SPECIFICATION | |
| Angle Adjustment | Pan: 0°~360°; Tilt:0°~80°; Rotation: 0°~360° |
| Audio | 1CH audio input; 1CH built-in MIC |
| Bit Rate | 64 Kbps ~12Mbps |
| Focus | Fixed |
| Image Sensor | 1 / 2.8 “CMOS |
| Resolution | 8MP (3840×2160), 6MP (3200×1800), 4MP (2688×1520), 2K (2560×1440), 1080P (1920×1080), 720P (1280×720), D1, VGA (640×480), 640×360, 480×240, CIF |
| Security | Video encryption, firmware encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP |
| Weight | Approx. 0.42KG |
| Storage | Built-in micro-SD card slot, up to 256GB |
| Dimensions | 167.6 × 75 × 74.6 |
| Power Supply | DC12V/PoE |
| INPUT | |
| Audio Compression | G711A/U |
| Video Compression | Main stream: H.265+/ H.265 / H.264+/ H.264 Sub /Third stream: H.265+/ H.265 / H.264+/ H.264 / MJPEG |
