| Camera Specification |
| Model |
PLC-434M-AU-PV3/PM |
| Image Sensor |
1/2.9″ CMOS |
| Resolution |
4MP (2688 × 1520) |
| Electronic Shutter |
Auto / Manual (1/3s ~ 1/100000s) |
| Lens |
2.8mm / 3.6mm Fixed Lens (F1.0, M12 Mount) |
| Minimum Illumination |
0.0005 Lux @F1.0 (AGC ON), 0 Lux with White Light |
| Wide Dynamic Range |
120dB True WDR |
| BLC / HLC / Defog |
Yes |
| Image Stabilization |
EIS (Electronic Image Stabilization) |
| Digital Noise Reduction |
3D DNR |
| Angle Adjustment |
Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360° |
| Video |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Frame Rate |
4MP / 2K / 1080P @30fps |
| Bit Rate |
32Kbps ~ 8Mbps (VBR / CBR) |
| Audio |
1CH Audio Input + Built-in Microphone (G711A/U) |
| AI Features |
| Perimeter Protection |
Line Crossing, Region Intrusion, Region Entrance & Exit (Human/Vehicle Classification) |
| Face Detection |
Face Detection & Face Capture |
| People Counting |
Target Counting by Line (Human/Vehicle) |
| Other AI Events |
Abandoned/Missing Object Detection, Scene Change, Audio Exception, Smart Motion Detection (SMD) |
| Network & Storage |
| Network Interface |
RJ45 (10/100 Base-T) |
| Storage |
MicroSD Card Slot (Up to 512GB) |
| Remote Monitoring |
Web Client, POLLO NVR, PVMS Plus, Mobile App |
| Online Users |
Up to 10 Simultaneous Users |
| Physical & Environmental |
| Power Supply |
DC12V / PoE (IEEE802.3af) |
| White Light Range |
20–30m |
| Protection Rating |
IP67 |
| Installation |
Ceiling Mount / Wall Mount |
| Weight |
Approx. 0.40kg |
| Certifications |
CE, FCC, RoHS, WEEE, REACH |
