| Camera Specification |
| Model |
PLC-424P-AU-DL3/PM |
| Image Sensor |
1/1.8″ Progressive Scan CMOS |
| Resolution |
4MP (2560 × 1440) |
| Electronic Shutter |
1/3s ~ 1/100000s |
| Lens |
2.8mm / 3.6mm Fixed Lens (M12 Mount) |
| Minimum Illumination |
0.0001 Lux @ F1.0 (AGC ON), 0 Lux with Illuminator |
| Day & Night |
ICR |
| Wide Dynamic Range |
120 dB True WDR |
| BLC / HLC |
Yes |
| Digital Noise Reduction |
Yes |
| S/N Ratio |
≥50dB |
| Angle Adjustment |
Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360° |
| Video |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Frame Rate |
4MP / 3MP / 1080P / 720P @30fps |
| Bit Rate |
64 Kbps ~ 3 Mbps (VBR / CBR) |
| Audio |
1CH Built-in Microphone (G.711A/U) |
| Network & Smart Features |
| Network Interface |
RJ45, ONVIF |
| Remote Monitoring |
Web Browser, POLLO NVR, PVMS Plus, Pollo Live Plus App |
| Motion Detection |
AI Smart Motion Detection (Human Filtering) |
| Smart Events |
Human Line Crossing Detection, Human Region Intrusion Detection |
| General Functions |
Watermark, Video Mask, Heartbeat |
| Security |
Video & Firmware Encryption, IP Filtering, 802.1X Authentication, HTTP Authentication |
| Network Protocols |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, HTTP, ONVIF |
| Power & Physical |
| PoE |
IEEE 802.3af |
| Night Vision |
20–30m IR + White Light |
| Ingress Protection |
IP67 |
| Power Supply |
DC12V / PoE |
| Power Consumption |
< 5W |
| Operating Temperature |
-20°C ~ 55°C |
| Dimensions |
162.1 × 74.8 × 73.8 mm |
| Weight |
Approx. 0.25 kg |
| Installation |
Ceiling Mount / Wall Mount |
| Certifications |
CE, FCC, RoHS, WEEE, REACH |
