| Camera Specification |
| Model |
PLC-428M-AU-DL3/PM |
| Image Sensor |
1/2.8″ CMOS |
| Resolution |
8MP (3840 × 2160) |
| Electronic Shutter |
1/3s ~ 1/100000s |
| Lens |
2.8mm / 3.6mm Fixed Lens (F1.6, M12 Mount) |
| Minimum Illumination |
0.02 Lux @F1.6 (AGC ON), 0 Lux with IR/White Light |
| Day & Night |
ICR |
| Wide Dynamic Range |
120dB True WDR |
| BLC / HLC / Defog |
Yes |
| Digital Noise Reduction |
Yes |
| IR / White Light Range |
20–30m |
| Video |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Frame Rate |
8MP @20fps, 6MP/4MP/2K/1080P @30fps |
| Bit Rate |
64Kbps ~ 12Mbps (VBR / CBR) |
| Audio |
1CH Audio Input + Built-in Microphone (G711A/U) |
| AI Features |
| Smart Events |
Line Crossing, Region Intrusion, Human/Vehicle Classification, Abandoned & Missing Object Detection |
| Smart Alarm |
Motion Detection, Smart Motion Detection (SMD), SD Card Error/Full, IP Conflict, Cable Disconnection, Video Exception |
| General Functions |
Watermark, Image Distortion Correction, Corridor Mode, Smart Supplement Light, Video Mask, Heartbeat |
| Network & Storage |
| Network Interface |
RJ45 Ethernet |
| Storage |
MicroSD Card Slot (Up to 256GB) & Network Storage |
| Remote Monitoring |
Web Browser, PVMS Plus, Pollo Live Plus Mobile App |
| Supported Users |
Up to 10 Simultaneous Users |
| Network Protocols |
IPv4/IPv6, RTSP, RTP, RTCP, RTMP, HTTP, HTTPS, FTP, SMTP, P2P, QoS, ONVIF |
| Physical & Environmental |
| Power Supply |
DC12V / PoE (IEEE802.3af) |
| Power Consumption |
<7W |
| Protection Rating |
IP67 |
| Dimensions |
167.6 × 75 × 74.6 mm |
| Weight |
Approx. 0.42kg |
| Installation |
Ceiling Mount / Wall Mount |
| Certifications |
CE, FCC, RoHS, WEEE, REACH |
