| Camera Specification |
| Model |
PLC-426M-AU-DL3/PM-E |
| Image Sensor |
1/2.5″ CMOS |
| Resolution |
6MP (3200 × 1800) |
| Electronic Shutter |
1/4s ~ 1/100000s |
| Lens |
2.8mm / 3.6mm Fixed Lens (F1.6, M12 Mount) |
| Minimum Illumination |
0.008 Lux @F1.6 (AGC ON), 0 Lux with Smart Dual Light |
| Day & Night |
ICR |
| Wide Dynamic Range |
120dB True WDR |
| BLC / HLC |
Yes |
| Digital Noise Reduction |
Yes |
| S/N Ratio |
≥50dB |
| Angle Adjustment |
Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360° |
| Video |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Frame Rate |
6MP @20fps, 4MP/1080P @30fps |
| Bit Rate |
64Kbps ~ 8Mbps (VBR / CBR) |
| Audio |
1CH Audio Input + Built-in Microphone (G.711A/U) |
| Smart Features |
| Smart Detection |
Motion Detection, Smart Motion Detection (SMD) |
| AI Events |
Human & Vehicle Detection, Line Crossing, Region Intrusion, Abandoned/Missing Object Detection, Video Exception |
| General Functions |
Watermark, Video Mask, Heartbeat, Smart Supplement Light, Corridor Mode, Configuration Backup |
| Network & Security |
| Network Interface |
RJ45 Ethernet |
| Protocols |
ONVIF, IPv4/IPv6, RTSP, HTTP/HTTPS, FTP, SMTP, QoS, SNMP |
| Remote Monitoring |
Web Browser, Pollo PVMS, Mobile App |
| Online Users |
Up to 6 Simultaneous Users |
| PoE |
IEEE 802.3af |
| Storage |
Network Remote Storage |
| Physical & Environmental |
| Supplement Light |
IR 20–30m + White Light 20–30m |
| Ingress Protection |
IP67 Weatherproof |
| Power Supply |
DC12V / PoE |
| Power Consumption |
≤6.5W |
| Operating Temperature |
-30°C ~ 60°C |
| Dimensions |
167.6 × 75 × 74.6 mm |
| Weight |
Approx. 0.45kg |
| Installation |
Ceiling Mount / Wall Mount |
| Certifications |
CE, FCC, RoHS, WEEE, REACH |
