| Camera Specification |
| Model |
PLC-432M-AUK-IR3/PM |
| Image Sensor |
1/2.8″ CMOS |
| Resolution |
2MP Full HD (1920 × 1080) |
| Electronic Shutter |
1/3s ~ 1/100000s |
| Lens |
2.8mm / 3.6mm Fixed Lens (M12 Mount) |
| Minimum Illumination |
0.008 Lux @ F1.6 (AGC ON), 0 Lux with IR |
| Day & Night |
ICR |
| Wide Dynamic Range |
Digital WDR |
| BLC / HLC |
Yes |
| Digital Noise Reduction |
Yes |
| Angle Adjustment |
Pan: 0°~355°; Tilt: 0°~70°; Rotation: 0°~355° |
| Video |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Frame Rate |
1080P / 720P @ 30fps (60Hz), 25fps (50Hz) |
| Bit Rate |
128 Kbps ~ 4 Mbps (VBR / CBR) |
| Audio |
1CH Audio Input |
| Storage & Network |
| Storage |
MicroSD Card Slot (Up to 256GB), Network Storage |
| Network Interface |
RJ45, ONVIF |
| Remote Monitoring |
Web Browser, PVMS Plus, Pollo Live Plus |
| Supported Browsers |
IE, Chrome, Edge, Firefox, Safari |
| Smart Alarm |
Motion Detection, SD Card Full/Error |
| Smart Events |
Line Crossing, Region Intrusion, Scene Change, Video Blur, Video Cast Detection |
| General Functions |
Watermark, Video Mask, Heartbeat, IP Filtering, Illegal Login Lock |
| Network Protocols |
UDP, IPv4, IPv6, DHCP, RTSP, RTP, RTCP, HTTP/HTTPS, FTP, SMTP, QoS, SNMP, UPnP |
| Power & Physical |
| PoE |
IEEE 802.3af |
| IR Night Vision |
20–30m |
| Protection Rating |
IP67 & IK10 |
| Power Supply |
DC12V / PoE |
| Power Consumption |
< 3.5W |
| Operating Temperature |
-30°C ~ 60°C |
| Dimensions |
Ø110 × 83.3 mm |
| Weight |
Approx. 0.5 kg |
| Installation |
Ceiling Mount (Wall Mount with Bracket) |
| Certifications |
CE, FCC, RoHS, WEEE, REACH |
