Description
| Model | PLC-338M-IR3/PM |
| Image Sensor | 1 / 2.5″ CMOS |
| Resolution | 8MP @ 15fps (Max) |
| Image Size | 3840 × 2160 |
| Video Output | AHD / TVI / CVI / CVBS |
| Image System | PAL / NTSC |
| Electronic Shutter | Auto |
| IR Distance | 20 ~ 30 m |
| Frame Rate | 15fps (60Hz), 12.5fps (50Hz) |
| Minimum Illumination | Color: 0.01 Lux @ F1.2 (AGC ON); B/W: 0 Lux with IR |
| Lens | 3.6 mm |
| Lens Mount | M12 |
| S / N Ratio | ≥52dB (AGC OFF) |
| Ingress Protection | IP67 |
| Function Control | OSD (COC Control) |
| Day & Night | ICR |
| Digital WDR | Yes |
| Digital Noise Reduction | Yes |
| AGC | Yes |
| Auto White Balance | Yes |
| Backlight Compensation (BLC) | Yes |
| Defog | No |
| Lens Shading Correction (LSC) | No |
| Highlight Compensation (HLC) | No |
| Sharpness | Yes |
| Mirror | No |
| Smart IR | No |
| Image Setting | Yes |
| Defect Correction | Auto |
| Language | English |
| Angle Adjustment | Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360° |
| Power Supply | DC12V (±10%) |
| Power Consumption | IR OFF: <1W; IR ON: <4W |
| Working Environment | -30°C ~ 50°C, 10% ~ 90% (Humidity) |
| Dimensions | Ø 94.6 × 82.8 mm |
| Weight (Net) | Approx. 0.41 kg |
