| Image Sensor |
1/3″ CMOS |
| Resolution |
4MP (2560 × 1440) |
| Lens |
2.8mm @ F2.2 (Optional: 3.6mm) |
| Field of View |
2.8mm: H:96°, V:53.7°, D:112° | 3.6mm: H:74.5°, V:41.5°, D:86.5° |
| Lens Mount |
M12 |
| Minimum Illumination |
0.09 Lux @ F2.2 (AGC ON); 0 Lux with Illuminator |
| Electronic Shutter |
1s ~ 1/100000s |
| Focus |
Fixed |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Supported Resolution |
4MP, 3MP, 1080P, 720P, D1, VGA, 480×240, CIF |
| Bit Rate |
64 Kbps – 3 Mbps |
| Audio |
Built-in Microphone (1CH), G.711A/U |
| Network |
RJ45 Ethernet |
| Storage |
Network Remote Storage |
| Remote Monitoring |
Web Browser, POLLO NVR, PVMS Plus, Pollo Live Plus Mobile App |
| Security |
Video Encryption, Firmware Encryption, Illegal Login Lock, IP Filtering, HTTP Authentication |
| Ingress Protection |
IP67 Weatherproof |
| Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–80°, Rotation: 0°–360° |
| Power Supply |
DC12V / PoE |
| Power Consumption |
< 5W |
| Operating Temperature |
-20°C to +55°C |
| Storage Temperature |
-20°C to +60°C |
| Dimensions |
162.1 × 74.8 × 73.8 mm |
| Weight |
Approx. 0.25 kg |
